Coating Improving the Wear Resistance of Aeroengine Bearing in Insufficient Lubrication

Time:2019-12-16 14:50:51  From:  Author:



Traditional lubrication by oil sometimes does not work because of the high temperature, fast speed and excessive load of the aeroengine bearings. The Graphite-like Carbon coating is used to improve the insufficient lubrication in this paper. And the micro hardness, the friction coefficient and the wear rate tests are offered: with GLC, the hardness is increased twice at least, its friction coefficient is 25 and the wear rate is 1/100 when contrasted with that of the typical bearing's material. The tests and calculation results show:the wear cycles of the GLC coated W9Cr4V is more than 400 times of that of the uncoated W9Cr4V and even when the GLC coating is worn out, the friction coefficient of W9Cr4V is only 0.15 which can effectively lubricate for the bearing for a short period of time when the liquid lubrication does not work. So it is proved to be effective in improving the wear resistance and reliability of bearings. In this paperthe important conclusions are given below(1)the hardness of the materials surface is increased twice at least with GLC coating(2)the coefficient of the GLC is l4 of that of W9Cr4VAnd the coefficient remains stably below 0.15 while tests is going on. The wear rate of the GLC is l5 of  W9Cr4v. With GLC the W9Cr4V can keeping self-lubricated for a long time when the liquid lubrication doest work(3)the tests and the calculated results showthe friction coefficient increased to 0.5 and the friction moment is as much as 22of the turning moment of the shaft when the wearing cycles are 700And a 2(pm)thick coating will be worn through after 280000 wearing cycles which is 400 times of those when the bearing is not GLC coatedIf the friction coeffcient can be kept low even after the coating is worn outthe number of wearing cycles will reach 840000 and the wear lifc can be prolonged by 1200 times compared with that of the uncoated material.
